Jeep CJ7 Parts & Accessories
 |
| Model Versions: Renegade, Laredo, Golden Eagle Technical Specifications: Wheelbase: 2375 mm Engine: AMC 3,8L (S6-232) (1976-78) AMC 4,2L (S6-258) (1976-86) AMC 5,0L (V8-304) (1976-81) GM 2,5L (S4-151) (1980-83) AMC 2,5L (S4-150) (1983-86) Automatic Transmission: GM TH-400 (1976-79) (with QuadraTrac #1339) TF-999 (32RH) 4,2L (1976-86) (with Dana 300) TF-904 (30RH) 2,5L (1980-83) (with Dana 300) |
| Transmission: T150 3-Speed (1976-79) with Dana 20 T18 4-Speed (1976-84) with Dana 20 T4 4-Speed (1982-86) with Dana 300 T5 5-Speed (1982-86) with Dana 300 T176 4-Speed (1980-86) with Dana 300 T177 4-Speed (1980-86) with Dana 300 SR4 4-Speed (1980-83) with Dana 300 Transfer Case: Dana 20 (1976-79) Dana 300 (1980-86) QuadraTrac #1339 (1976-79) Axle: Front Axle: Dana 30 (1976-86) Rear Axle: AMC 20 (1976-86), Dana 44 (1986) |
From Steering Knuckle to Bikini Top – 19 Assembly Groups for Restoration and Everyday Use (1976-1986)
The Jeep CJ7 – more wheelbase, more comfort, more possibilities
In 1976, AMC launched the CJ7 for everyone who found the CJ5 too cramped. The wheelbase grew to 2375 mm, and the door openings became wider and squarer. For the first time, a CJ was available with an automatic transmission and the Quadra-Trac full-time four-wheel drive. The factory also offered a moulded hardtop and steel doors with roll-up windows. The drivetrain changed considerably over the years: up to 1979 the Dana 20 transfer case worked with T150 and T18 gearboxes, and from 1980 the Dana 300 took over alongside the T176/T177, SR4, T4 and T5. Engines ranged from the 2.5-litre four-cylinders by GM and AMC through the 3.8 and 4.2-litre inline sixes to the 5.0-litre V8. Trim levels such as Renegade, Laredo and Golden Eagle turned the CJ7 into a classic, until production ended in 1986 and the Wrangler YJ took over. Anyone restoring one today should therefore know the model year and drivetrain of their CJ7 first.
From Crown to Bestop: the right CJ7 parts by assembly group
For the cabin you will find Interior parts such as door handles, seat belts and dash trim. On the body, Body Parts, Body Weatherstrips and Wiper Linkage Parts keep the CJ7 sealed and roadworthy. The Soft Tops are divided into Complete Soft Tops, Bikini Tops, Windjammers & Duster Covers and Soft Top Gear & Storage Bags. The Accessories section splits into Seats & Interior Accessories and Exterior Accessories. Crown Automotive supplies most of the sheet metal and small parts here. MD Juan provides body tubs, Fairchild the weatherstrips, and Bestop together with Pavement Ends the soft tops. Omix and RT Off-Road add accessories and stainless parts.
On the drivetrain side, Engine Parts lead to the 2.5L AMC, 2.5L GM Iron Duke, 3.8L & 4.2L and 5.0L & 5.9L V8 engines. The Manual Transmission section is sorted by type: T150, T18, T176 & T177, SR4, T4 and T5. The Transfer Case section covers the Dana 20, Dana 300 and Quadra-Trac. The Clutch and its linkage complete the drivetrain. Alongside Crown Automotive, Enginetech and Sealed Power supply internal engine parts, Dana Spicer transfer case components, and Platinum Driveline and LUK clutch parts.
The Axle & Differential section takes you straight to the Dana 30 Front Axle, AMC 20 Rear Axle, Dana 44 Rear Axle and Driveshaft parts. Suspension and Steering keep the CJ7 tracking straight. Dana Spicer supplies genuine axle components, Prothane and Daystar polyurethane bushings, Bilstein from Germany the shock absorbers, and Lares steering parts.
Brakes from Raybestos, Dorman and Crown Automotive, with lines from Classic Tube, take care of safety. The Electrical section splits into Engine Electrical, with ignition parts from Standard Ignition and Champion, and Body Electrical, with lights from Hella. Cooling, Fuel System and Exhaust round out the range, with parts from Gates, Walker Exhaust, AP Exhaust and Flowtech, among others.
For routine maintenance, Service & Maintenance brings together spark plugs, filters and belts from Champion, Standard Ignition, Gates and ATP. Across all assembly groups, most parts come from American manufacturers, complemented by German brands such as Bilstein and Hella.
Which transmission is in your CJ7? Advice before you buy
T150 or T176, Dana 20 or Dana 300, AMC 20 or Dana 44: on a CJ7, the right part number often depends on the model year and the drivetrain fitted. We help you identify your vehicle clearly and advise on torque specs, installation order and fitment on the CJ5, CJ8 and Wrangler YJ. That way you order the right part the first time. Fast dispatch from stock in Germany.
