Dana 30 Front Axle Parts for Jeep CJ6
Wheel Bearings, Axle Shafts, U-Joints & Ball Joints at a Glance (1972-1975).
Why the Dana 30 Front Axle Needs Special Care in the Final CJ6 Model Years.
Starting in 1972, Jeep switched the CJ6 to the wider, sturdier Dana 30 as its front axle – the same axle also used in the CJ5, CJ7, and CJ8. Unlike the earlier Dana 25/27 axles, the Dana 30 uses ball joints instead of king pins, allowing more steering angle but also introducing its own wear points. Over time, moisture and vibration take their toll on the U-joints, ball joints, and the ring-and-pinion set inside the differential – steering play, a rough-running pinion, or oil leaking at the differential cover are typical signs. Wheel bearings and axle shaft seals wear from the constant load as well. Anyone restoring a late-model CJ6 chassis or driving it off-road should check the front axle regularly for ball joint play and differential noise.
- Axle Shafts & Seals: The axle shaft seal and the outer wheel bearing for a tight, play-free axle shaft.
- Wheel Hub Hardware: The wheel bearing nut socket and the wheel bearing nut kit for the wheel bearing setup.
- Driveline & U-Joints: The axle shaft U-joint and the propeller shaft yoke for reliable power transfer.
- Ring & Pinion Sets: The 3.54 ring-and-pinion set and the inner pinion bearing kit for a freshly rebuilt differential.
- Ball Joints & Spindle: The ball joint kit, upper and lower and the axle spindle bearing kit for the steering geometry.
American Brand Quality for Your Front Axle.
U-joints, ring-and-pinion sets, pinion bearings, and ball joints come from Dana Spicer, the original manufacturer of the Dana 30 axle. Crown Automotive rounds out the range with wheel bearings, spindle bearing kits, and differential parts. Both brands stand for American engineering straight from the axle's country of origin.
Your Partner for the Dana 30 Front Axle.
Whether you're replacing a single ball joint or rebuilding the entire differential, we're happy to advise you on shims, torque specs, and the right gear ratio for your CJ6. Most items are in stock and ship out quickly.
